Photo Gallery



This plate illustrates the abilities of the 5-axis waterjet. The text reads the same from both sides, meaning that each letter transitions to a different letter on the opposite side.
Aquajet services 5 axis waterjet steam cap
Waterjet cut through a 16-1/2' thick billet of Waspaloy (a high strength super alloy). The 10,000 pound billet was severed into four pieces.
Small waterjet cut parts. In spite of their intricacy, these parts are accurate to within +/-.005.
Vinyl floor medallion.
Aluminum tube sculpture built for Emil Lukas, an artist from Stockertown, PA. The sculpture measures 8'-9'' high x 12' across.
Cast iron speaker for Oswald's Mill Audio — cast in one piece using a 3D printed sand mold. We did all the 3D modeling for the casting and the molds.
Stainless steel hoppers.
Stainless steel trashrack for a reservoir at a nuclear power plant.
Windows cut into large aluminum tubes using our 5-axis waterjet.
Wavy aluminum part cut with our 5-axis waterjet. The part is one component of an elaborate hanging art sculpture made for Durham Press.
3D rendering of a large steel fabrication which we designed and built.
Heavy steel weldment.
Thick steel plates cut using our 5-axis waterjet.
Waterjet cutting a 7' thick ingot of a niobium alloy into slices.
Thick Waspaloy plates cut using our 5-axis waterjet.
These parts were waterjet cut and then roll formed, after which the angled oblong cuts became round concentric holes through the walls of the tube.
Turntable plinths for Oswald's Mill Audio, waterjet cut out of thick gray slate. We do all of OMA's slate cutting.
Decorative knob waterjet cut out of 1' thick stainless steel.
Small waterjet cut and formed parts.
Waterjet cutting titanium.
Steel mezzanine fabrication, loaded up for delivery on our 32' flatbed trailer.
We built this stainless steel coal truck body and rebuilt the truck's scissor lift mechanism.
This bracket was waterjet cut and formed out of a single piece of 3/16' thick polycarbonate, to replace the customer's original design which consisted of four individual pieces, pinned together.
Waterjet cut and formed stainless steel part.
We designed and built a number of these snow pushers, ranging from 6' wide to 20' wide.
Stainless steel wash station that we designed and built for a local recycling business. Its purpose is to separate dirt and foreign materials from shredded plastic product.
Aquajet services 5 axis waterjet glass art sculpture jed malitz v2
